NZXT H510 ELITE PREMIUM COMPACT MID-TOWER ATX GAMING CASE

FEATURES

Two tinted tempered glass panels for showcasing stunning RGB ...builds.
Two Aer RGB 2 fans and one RGB LED are included
Removable radiator mounting bracket and simple-to-use SSD trays
Patented cable management system
Smart Device 2 with two RGB lighting channels and three fan channels that support 0dB modes for voltage-regulated or PWM fans
USB 3.1 Gen 2-compatible USB-C connector
Iconic cable management bar

FULL SPECS

Motherboard Support: Mini-ITX, Micro ATX, ATX
Enclosure Type: Compact Mid-Tower
Case Material: SGCC Steel, Dark Tinted Tempered Glass

Dimensions

Height:460mm / 18.11 inches
Width:210mm / 8.27 inches
Depth:428mm / 16.85 inches
Weight:7.5 kg / 16.53 lb

Compatibility & Clearance

Max CPU Cooler Clearance:165mm
Max GPU Clearance:338 – 368mm
Front Fan & Radiator Clearance:60mm
Vertical GPU Clearance:50.8mm
Cable Management:19 – 23mm

Front I/O Ports

USB 3.2 Gen 1 Type-A:1
USB 3.2 Gen 1 Type-C:1
Headset Audio Jack:1

Smart Device

Fan Channels:3 (10W max per channel)
NZXT RGB Connector:2 (Support up to 40 LEDs)

Expansion Slots

Standard:7
Vertical:2

Drive Bays

2.5″:2 + 1
3.5″:2 + 1

Fan Support

Front:2 x 120mm / 2 x 140mm
Top:1 x 120mm / 1 x 140mm
Rear:1 x 120mm
Filters: All air intakes

Radiator Support

Front:280mm
Top:–
Rear:120mm

Fan Specs

Model: Aer RGB 2 140mm
Speed:500 – 1,500 ± 300RPM
Airflow:30.39 – 91.19 CFM
Static Pressure:0.17 – 1.52 mm-H₂O
Noise:22 – 33 dBA
Fan Connector:4-pin PWM

Fan Specs

Model: Aer P 140mm (Case Version)
Speed:1,000 ± 200RPM
Airflow:68.95 CFM
Noise:28 dBA
Fan Connector:3-pin

Fan Specs

Model: Aer P 120mm (Case Version)
Speed:1,200 ± 200RPM
Airflow:50.42 CFM
Noise:28 dBA
Fan Connector:3-pin

₱8,500.00
